Acrylic foam tape 3M VHB tape for curtain wall

Short Description:

Produc Description VHB tape is a polyacrylate two-sided foam tape manufactured using a unique solvent-free manufacturing technology. The foam core and the top layer of adhesive are all made of polyacrylate-based viscoelastic but not on both sides of the foam core Coating adhesives, which are the biggest differences between VHB ? tape products and common foam tapes, are vividly called “solid glue.” This special structure gives the adhesive tape a special overall viscoelasticity. Th...


  • Die Cutting: Available
  • Customized Solution: Available
  • Factory Inspection: Available
  • Samples Delivery day: 3 days by air express
  • Certification: SGS, ROSH, ISO
  • Product Detail

    Product Tags

    Produc Description

    VHB tape is a polyacrylate two-sided foam tape manufactured using a unique solvent-free manufacturing technology. The foam core and the top layer of adhesive are all made of polyacrylate-based viscoelastic but not on both sides of the foam core Coating adhesives, which are the biggest differences between VHB ? tape products and common foam tapes, are vividly called “solid glue.” This special structure gives the adhesive tape a special overall viscoelasticity. The adhesive tape can effectively dissipate the stress inside the adhesive joint through mechanical relaxation of the adhesive tape so as to effectively protect the bonding wire. The foam core of VHB tape is a 100% fully closed cell structure that does not pass water or air.

    Structure

    Acrylic PSA
    Acrylic Foam
    Acrylic PSA
    Release film

    Feature

    • Strong adhesive
    • Good waterproof
    • UV resistance
    • Peel strength
    • Good weatherability
    • Environmentally friendly
    • No import restrictions
    • Simple processing

    Application

    • Glass curtain wall assembly dust seal
    • Construction work, such as insulation, connection, binding, modification, sealing
    • Electronics, digital product assembly and processing
    • Automotive Industry: Nameplates, Trims, Markers, Ideal Replacement for 3M VHB Tape

    VHB tapes have been used successfully in many fields, such as sheet metal curtain wall, glass curtain wall, elevator assembly, transportation market, etc. to introduce the application of VHB ? tape products in the most demanding construction market. For more than 20 years, VHB ? tape has been used worldwide for a wide range of interior and exterior curtain wall panels bonded to frames and stiffeners such as the Curtain Wall Project dating back to the Singapore Treasury Building project in 1985, the other Of the more famous sheet metal curtain wall In addition to the Dubai Arabian Tower, as well as ambitious Dubai Commercial Bay, the Russian Federation Building, etc .; glass curtain wall project as early as 1990 Urcov Building project in Brazil, in addition to the United States Liberty Memorial Museum, Philips HQ in Germany and Athenee Plaza Tower in Thailand

    Data Sheet

    Item Unit Value Test Method
    Carrier   Acrylic Foam
    Adhesive   Acrylic
    Color   Clear
    Thickness mm 1.00±50μm ASTM-1000
    Standard Roll Width mm 800
    Standard Roll Length m 33
    Tensile Strength Gf/cm² ≥7,000 (T-Block)To Aluminum
    Peel Adhesion gf/25mm ≥4,000 To Stainless SteelRoom Temperature

    180°Peel

    Holding Power  Hr >24 To Stainless Steel80℃Temperature

    1000g Static Load
