Die Cutting Silicone Sponge Gasket Sheet for Seals, Press Pads, Thermal Insulating

Short Description:

Product Description Commercial grade silicone sponge sheet is designed for high performance gasket, thermal shielding, vibration mounts and press pads. Silicone exhibits a wish list of characteristics including superb chemical resistance, high temperature performance, good thermal and electrical resistance, long-term resiliency, and easy fabrication. It also possesses excellent UV and ozone resistance. Silicone is odorless, tasteless and non-toxic. Silicone sponge rubber is most commonly red ...


  • Die Cutting: Available
  • Customized Solution: Available
  • Factory Inspection: Available
  • Samples Delivery day: 3 days by air express
  • Certification: SGS, ROSH, ISO
  • Product Detail

    Product Tags

    Product Description

    Commercial grade silicone sponge sheet is designed for high performance gasket, thermal shielding, vibration mounts and press pads. Silicone exhibits a wish list of characteristics including superb chemical resistance, high temperature performance, good thermal and electrical resistance, long-term resiliency, and easy fabrication. It also possesses excellent UV and ozone resistance. Silicone is odorless, tasteless and non-toxic. Silicone sponge rubber is most commonly red in color although it is also available in grey, black or white with a fine fabric finish on both sides.

    Features

    • High temperature resistance.
    • Chemical, ozone and UV resistant.
    • Low compression set and easy fabrication.

    Datasheet

    Property

    Specification AMS3195

    Typical Values

    Density, lbs/cubic in. under ¼” thk.

    .025 Max

    .020

    Density, lbs/cubic in. over ¼” thk.

    .020 Max

    .018

    Compression Deflection, PSI

    6-14

    11

    Compression set, 22 hrs @212°F

    60% Max

    29

    Brittle Point °F

    -67

    -103

    Temperature Range °F

    N/A

    -103 to +450

    Water Absorption

    5% Max

    Pass

    Tensile Strength, PSI

    N/A

    100

    Elongation %

    N/A

    200

    Thermal Conductivity BTU in./hr. ft² ºF

    N/A

    6

    Applications

    • Gasket applications that require a soft compressible material.
    • Seals, press pads, thermal insulating, thermal shielding, heat transfer.
    • Silk screening, print presses, and vibration mounts.
