Electrical Insulating Fish Paper Vulcanized Fiber Sheet for Transfomer and Battery

Short Description:

Description Fishpaper is a durable, flexible, electrical insulator that’s made of vulcanized fiber and used with motor windings and for gasket insulation. A lightweight dielectric paper, this electrical grade material is also a good choice for oil-filled transformers. Features Outstanding dielectric properties Fishpaper electrical insulation has good mechanical strength because it’s fibrous This hard, wear-resistant cellulosic paper is more heat-resistant than many plastic materials Re...


  • Die Cutting: Available
  • Customized Solution: Available
  • Factory Inspection: Available
  • Samples Delivery day: 3 days by air express
  • Certification: SGS, ROSH, ISO
  • Product Detail

    Product Tags

    Description

    Fishpaper is a durable, flexible, electrical insulator that’s made of vulcanized fiber and used with motor windings and for gasket insulation. A lightweight dielectric paper, this electrical grade material is also a good choice for oil-filled transformers.

    Features

    1. Outstanding dielectric properties
    2. Fishpaper electrical insulation has good mechanical strength because it’s fibrous
    3. This hard, wear-resistant cellulosic paper is more heat-resistant than many plastic materials
    4. Retains greater flexibility than plastics at low temperatures

    Datasheet

    Physical Characteristics

    Standard Values

    Material

    Vulcanized Fiber

    Color

    Green

    Thickness

    0.1 mm-2 mm

    Dimension

    Sheets, Rolls, or Slit to Coils

    Application

    Electrical Insulation

    Tensile Strength

    10.4Mpa

    Temperature

    115° C

    Application

    • Electrical instruments
    • Appliances
    • Various automotive parts and components
    • Electronic devices
    • Fuse tubes
    • Circuit breakers
    • Gaskets
    • Motor contact bushings
    • Railroad track insulation
