Electrical Insulating Teflon PTFE Skived Film tape for Surface Anti-sticking Treatment

Short Description:

Product Description PTFE skived film tape is made from a skived and tensilized PTFE film with high temperature silicone adhesive , is used for kinds of surface anti-sticking treatment. It has a unique combination of performance,the tensilized film provides higher tensile strength, lower elongation and higher dielectric strength than regular skived film. It provides superior material solutions for engineers and designers. This tape is currently the most versatile high-performance heat-resistan...


  • Die Cutting: Available
  • Customized Solution: Available
  • Factory Inspection: Available
  • Samples Delivery day: 3 days by air express
  • Certification: SGS, ROSH, ISO
  • Product Detail

    Product Tags

    Product Description

    PTFE skived film tape is made from a skived and tensilized PTFE film with high temperature silicone adhesive , is used for kinds of surface anti-sticking treatment. It has a unique combination of performance,the tensilized film provides higher tensile strength, lower elongation and higher dielectric strength than regular skived film. It provides superior material solutions for engineers and designers. This tape is currently the most versatile high-performance heat-resistant, chemical-resistant, abrasion-resistant tape.

    Structure

    Silicone adhesive
    PTFE skived film

    Features

    1. High heat resistance. Resistant to 260 degrees Celsius processing temperature.
    2. Easy to remove stains: smooth surface, easy to adhere to any substance. Easy to clean and adhere to the surface of a variety of grease, stains or other attachments; paste, resin, paint, etc. Almost all sticky substances can be simply removed.
    3. Wide range of chemical resistance: chemical resistance even better than many precious metals.
    4. Electrical stability: a variety of temperature and humidity dielectric properties are very stable.
    5. With high insulation properties, anti-UV, anti-static.
    6. Low humidity.
    7. Easy to use, long service life.

    Application

    1. For food and beverage plastic packaging industry heat sealing machine and high-speed heat sealing machine.
    2. Various dryer dryer tube surface anti-sticking treatment;
    3. Lamination machine dryer surface anti-sticking treatment;
    4. Guide roller, roller surface anti-sticking treatment;
    5. Paper machine drying cylinder surface anti-sticking treatment;
    6. Other surface anti-adhesive glue, anti-stick color, reduce the friction of the application.

    Data sheet

    Property

    Test Method

    15-2HD

    15-3HD

    15-5HD

    Backing Material



    PTFE Film

    Film Thickness (in.)



    .002

    .003

    .005

    Adhesive System



    SILICONE

    Adhesive Thickness (in.)



    .0015

    Adhesion (oz/in)

    ASTM-D 1000

    25

    25

    30

    Tensile Strength (psi min)

    ASTM-D 3759

    11,000

    13,000

    7,500

    Elongation (%)

    ASTM-D 3759

    100

    100

    100

    Dielectric Strength (volts/mil)

    ASTM-D 149

    4,000

    3,000

    2,700

    Max. Operating Temp. (ºF)

    -100 to 500ºF
