Nitto 973 Teflon PTFE Fiberglass Cloth Tape for Heat-resistant Masking

Short Description:

Product Description Nitto 973 fiber class Teflon tape use Glass cloth as film with PTFE dispersion then sintered. Single surface treated and coated with a silicone adhesive, which exhibits excellent heat resistance and mechanical strength. Structures Silicon Adhesive PTFE Film Features UL510 certified. Environment-friendly and conforms to Notification No.20 of the Ministry of Health, Labor and Welfare. Superior mold-releasing and sliding properties. Good holding property at eleva...


  • Die Cutting: Available
  • Customized Solution: Available
  • Factory Inspection: Available
  • Samples Delivery day: 3 days by air express
  • Certification: SGS, ROSH, ISO
  • Product Detail

    Product Tags

    Product Description

    Nitto 973 fiber class Teflon tape use Glass cloth as film with PTFE dispersion then sintered. Single surface treated and coated with a silicone adhesive, which exhibits excellent heat resistance and mechanical strength.

    Structures

    Silicon Adhesive

    PTFE Film

    Features

    • UL510 certified.
    • Environment-friendly and conforms to Notification No.20 of the Ministry of Health, Labor and Welfare.
    • Superior mold-releasing and sliding properties.
    • Good holding property at elevated temperatures and dimensional stability.
    • The non-adhesive side exhibits excellent characteristics of PTFE such as electrical properties, resistance to heat, weather, chemical, and water (water-shedding), and non-adhesiveness.

    Data Sheet

    Item

    Unit

    No.973UL-S

    No.973UL

    Test Method

    Thickness

    mm

    0.13

    0.15

    0.18

    Compatible with JIS C 2107

    Thickness

    mil

    5.12

    5.91

    7.09

    Tensile strength

    N/19mm

    240

    590

    530

    Tensile strength

    lb/in

    72.1

    177

    160

    Adhesive strength

    25°C

    N/19mm

    6.8

    9.0

    9.7

    100°C

    3.2

    3.9

    4.7

    150°C

    2.2

    2.6

    3.0



    Adhesive strength

    77°F

    oz/in

    33

    43

    47



    212°F

    15

    19

    23



    302°F

    11

    13

    14



    Temperature range

    °C

    -60~200

    -

    Temperature range

    °F

    -76~392



    Applications

    • For heat-resistant masking.
    • For heat-sealing.
    • For heat-resistant electrical insulation.
